IntellaFlex XR Overview

IntellaFlex XR: Scalable and Flexible

IntellaFlex XR is a suite of integrated products that work together seamlessly to provide network visibility and security solutions.

Delivering complete traffic visibility in physical, virtual, and cloud environments.
Ten blades with a broad range of advanced features, five chassis provide exceptional scalability and reliability, and intuitive software for configuration and management.
It’s smart, integrated, intelligent and flexible – it’s IntellaFlex XR.

SEE ALL
TRAFFIC

AGGREGATE
AND FILTER

SCALE AND
CUSTOMIZE

MANAGE
EASILY

See All Traffic

If you can't see all your network traffic, you can't protect it. The integrated technologies of the APCON IntellaFlex XR solution help you get visibility of physical, virtual and cloud traffic. Direct traffic to any security or performance tool you want. Efficiency, speed, and security - your network demands it, IntellaFlex XR delivers it.

Aggregate And Filter

Collect and aggregate traffic from anywhere on your network - physical or virtual environments - enterprise datacenters or remote locations. Powerful multilayer filtering lets you capture exactly the traffic you want - and direct it to any network performance analysis or security tool.

Scale And Customize

IntellaFlex XR chassis are modular with interchangable and hot-swapable components. IT professionals can easily and cost efficiently add capacity with additional blades and software features to meet the demands of growing and more sophisticated networks.Efficiency, speed, and security - your network demands it, IntellaFlex XR delivers it.

Manage Easily

You would think that managing all the powerful capabilities and multiple configurations of the IntellaFlex XR platforms would be complicated. It isn't. Intuitive, user-friendly interfaces help manage all blades, and all chassis. Efficiency, speed, and security - your network demands it, IntellaFlex XR delivers it.

Blades

Ten different IntellaFlex XR blades with the broadest range of advanced features including time stamping, packet slicing, multi-stage filtering, data rate conversion protocol stripping and load balancing give security teams and network engineers the power to deliver the right data to the right tools all the time.

Learn More >

Chassis

IntellaFlex XR chassis are designed for networks that demand high availability and system compatibility. Five Models support 1, 2, 4, 8 and 14 blade capacities. Hot-swappable common components.

Learn More >

Software

WebXR | Build, save, view and recall device connections between SPANs/TAPs and monitoring tools with an easy to use GUI.

Learn More >

TitanXR and APCON Mobile App | TitanXR provides a single, centralized point of management for a multi-switch network visibility environment. The APCON Mobile App complements TitanXR by providing real time status of the APCON visibility infrastructure remotely.

Learn More >

IntellaFlex XR Blades

Aggregation / Filtering :: IntellaFlex Packet Aggregator Blade | 24 ports 1/10G and 8 ports 40G

learn more

Aggregation / Filtering :: IntellaFlex Packet Aggregator Blade | 36 ports 1/10G

learn more

Traffic Buffering :: IntellaFlex Traffic Manager Blade

learn more

IntellaStore II Blade

learn more

IntellaStore II+ Blade

learn more

IntellaFlex XR Chassis

IntellaFlex 3504-XR

learn more

IntellaFlex 3288-XR

learn more

IntellaFlex 3144-XR

learn more

IntellaFlex 3072-XR

learn more

IntellaFlex 3036-XR

learn more

IntellaFlex XR Software

WebXR - GUI management software for IntellaFlex XR switches

learn more

TitanXR - GUI management software for multiple IntellaFlex XR switches

learn more

IntellaFlex 3504-XR

Image shows a 14 RU chassis :: shown with 14 blades installed

IntellaFlex XR is a high performance network monitoring switch family with market-leading Ethernet capacity and state-of-the-art monitoring technology. The IntellaFlex 3504-XR intelligent network monitoring switch is the solution for high capacity enterprise-grade requirements in large data centers. The 3504-XR delivers up to 5.04 Terabits per second of data throughput among up to 504 non-blocking 10 Gbps Ethernet ports.

Part# :: ACI-3504-XR

Throughput :: Up to 5.04 Tbps switching (360 Gbps blade-to-blade) 1G up to 100G Ethernet switching architecture
Redundancy :: Controllers, power supplies, and fans
Hot Swappable :: Power supplies, blades and optics
XR Compatibility :: Controllers, power supplies, fans and blades compatible across all XR chassis
Software :: Easy-to-use WEBXR GUI plus CLI, SNMP and LCD

IntellaFlex 3288-XR

Image shows a 8RU chassis :: shown with 8 blades installed

IntellaFlexXR is a high performance network monitoring switch family with market-leading capacity and state-of-the-art monitoring technology. The 3288-XR Chassis is 8RU supporting up to 288 non-blocking Ethernet ports to monitor large enterprise networks.

Part# :: ACI-3288-XR

Throughput :: Up to 2.88 Tbps switching (360 Gbps blade-to-blade) 1G up to 100G Ethernet switching architecture
Redundancy :: Controllers, power supplies, and fans
Hot Swappable :: Power supplies, blades and optics
XR Compatibility :: Controllers, power supplies, fans and blades compatible across all XR chassis
Software :: Easy-to-use WEBXR GUI plus CLI, SNMP and LCD

IntellaFlex 3144-XR

Image shows a 4RU chassis :: shown with 4 blades installed

IntellaFlex XR is a high performance network monitoring switch family with market-leading capacity and state-of-the-art monitoring technology. The 3144-XR Chassis is 4RU supporting up to 144 non-blocking Ethernet ports to monitor large enterprise networks.

Part# :: ACI-3144-XR

Throughput :: Up to 1.44 Tbps switching (360 Gbps blade-to-blade) 1G up to 100G Ethernet switching architecture

Redundancy :: Controllers, power supplies, and fans
Hot Swappable :: Power supplies, blades and optics
XR Compatibility :: Controllers, power supplies, fans and blades compatible across all XR chassis
Software :: Easy-to-use WEBXR GUI plus CLI, SNMP and LCD

IntellaFlex 3072-XR

Image shows a 2RU chassis :: shown with 2 blades installed

IntellaFlex XR is a high performance network monitoring switch family with market-leading capacity and state-of-the-art monitoring technology. The 3072-XR Chassis is a 2RU supporting up to 72 non-blocking Ethernet ports.

Part# :: ACI-3072-XR

Throughput :: Up to 720 Gbps switching (360 Gbps blade-to-blade) 1G up to 100G Ethernet switching architecture
Redundancy :: Controllers, power supplies, and fans
Hot Swappable :: Power supplies, blades and optics
XR Compatibility :: Controllers, power supplies, fans and blades compatible across all XR chassis
Software :: Easy-to-use WEBXR GUI plus CLI, SNMP and LCD

IntellaFlex 3036-XR

Image shows a 1RU chassis :: shown with 1 blade installed

IntellaFlex XR is a high performance network monitoring switch family with market-leading capacity and state-of-the-art monitoring technology. The 3036-XR Chassis is a 1RU supporting up to 36 non-blocking Ethernet ports.

Part# :: ACI-3036-XR

Throughput :: All ports line rate > 200 byte packets | 1G up to 100G Ethernet switching architecture
Redundancy :: Power supplies, controller fans
Hot Swappable :: Power supplies, blades and optics
XR Compatibility :: Controllers, power supplies, fans and blades compatible across all XR chassis
Software :: Easy-to-use WEBXR GUI plus CLI, SNMP and LCD

200Gbps Processing :: HyperEngine Packet Processor Blade

The HyperEngine Packet Processor Blade includes 2 ports 40G Ethernet and 16 internal service points with up to 200Gbps processing capacity, for high performance packet processing applications.

Features :: Deduplication, NetFlow generation, Tunnel termination, Protocol Header Stripping and Deep Packet Inspection.

Part Number :: ACI-3033-E02-1

Interfaces :: 16 x internal service points up to 200Gbps | 2 x 40G QSFP Ethernet

QSFP :: 40GBASE-SR4/LR4

Aggregation / Filtering :: IntellaFlex Packet Aggregator Blade | 36 ports 1/10G

IntellaFlex Packet Aggregator Blade includes 36 ports 1/10G Ethernet with network monitoring aggregation, filtering and load balancing features. This blade is optimized for Ethernet network monitoring applications.

Features :: Aggregation, Filtering, Load Balancing, Any-to-Any and Multicast Connections, Multistage Filtering, and Port Tagging.

Part Number :: ACI-3030-E36-6

Interfaces :: 36 × 1G/10G SFP/SFP+ Ethernet

SFP/SFP+ :: 1000BASE-T/SX/LX, 10GBASE-SR/LR

XR Backplane :: 360Gbps backplane connectivity per blade

Aggregation / Filtering :: IntellaFlex Packet Aggregator Blade | 24 ports 1/10G and 8 ports 40G

IntellaFlex Packet Aggregator Blade includes 24 ports 1/10G and 8 ports 40G Ethernet with network monitoring aggregation, filtering and load balancing features. This blade is optimized for Ethernet network monitoring applications.

Features :: Aggregation, Filtering, Load Balancing, Any-to-Any and Multicast Connections, Multi Stage Filtering, and Port Tagging.

Part Number :: ACI-3030-E32-7

Interfaces :: 36 × 1G/10G SFP/SFP+ Ethernet | 8 × 40G QSFP Ethernet

SFP/SFP+ :: 1000BASE-T/SX/LX, 10GBASE-SR/LR

QSFP :: 0GBASE-SR4/LR4

XR Backplane :: 360Gbps backplane connectivity per blade

Aggregation / Filtering :: IntellaFlex 100G Packet Aggregator Blade

The IntellaFlex Packet Aggregator Blade includes 4 ports 100G Ethernet with aggregation and port tagging. This blade is optimized for Ethernet network monitoring applications.

Features :: Aggregation, Any-to-Any and Multicast Connections, and Port Tagging. Filtering and Load Balancing performed on mating 1G,10G, and 40G blades.

Part Number :: ACI-3011-E04-100-1

Interfaces :: 4 × 100G QSFP28 Ethernet

QSFP28 :: 100GBASE-SR4/LR4

XR Backplane :: 400 Gbps connectivity > 200byte packets

Features :: Aggregation, Any-to-Any and Multicast Connections, and Port Tagging. Filtering and Load Balancing performed on mating 1G,10G, and 40G blades.

Aggregation / Filtering :: IntellaFlex Multi Function Aggregator Blade

IntellaFlex Multi Function Aggregator Blade includes 36 ports 1/10G with standard IntellaFlex features plus advanced multi-function features: deduplication, packet slicing, protocol stripping and time stamping. This blade is optimized for advanced Ethernet network monitoring applications.

Features :: Aggregation, Filtering, Load Balancing, Any-to-Any and Multicast Connections, Multi Stage Filtering, Port Tagging, deduplication, packet slicing, protocol stripping, and time stamping. New Multi-Function Pipeline feature allows up to three operations to be performed on packets passing through a single port. For the user, this frees up ports and eases configuration.

Part Number :: ACI-3032-E36-1

Interfaces :: 36 × 1G/10G SFP/SFP+ Ethernet

SFP/SFP+ :: 1000BASE-T/SX/LX, 10GBASE-SR/LR

Performance :: All ports line rate > 200 byte packets

XR Backplane :: 360 Gbps backplane connectivity per blade

IntellaStore II Blade

IntellaStore II Blade includes dedicated data capture and storage for on-board traffic analysis and advanced multi-function features. With 12 ports 1G/10G and 2 ports 40G Ethernet, this blade is ideal for advanced network monitoring applications at mid-size businesses or remote locations.

Multi-Function :: Packet Slicing, Deduplication, Time Stamp, Protocol Stripping (FabricPath, VNTag, MPLS, GRE), Timing options GPS, IRIG-B, PTP, NTP. New Multi-Function Pipeline feature allows up to three operations to be performed on packets passing through a single port. For the user, this frees up ports and eases configuration.

Part Number :: ACI-3033-S14-1

SFP/SFP+ :: 1000BASE-T/SX/LX, 10GBASE-SR/LR

QSFP :: 40GBASE-SR4/LR4

Blade Performance :: All ports line rate > 200 byte packets

XR Backplane :: 360 Gbps backplane connectivity per blade

Application Processor :: Intel® Core™ i7 Quad Core Processor

XR Base Features :: Aggregation, Filtering, Load Balancing, Any-to-Any and Multicast Connections, Multi Stage Filtering, and Port Tagging.

Comparison Table :: IntellaStore II / IntellaStore II+

Security Tool Bypass :: IntellaFlex Bypass Switch

IntellaFlex Bypass Switch has 5 optical bypass 1/10G TAPs and up to 14 monitoring tool ports. It is a fail-safe passive TAP in bypass mode and features up to 7 in-line appliance support, load balancing to support redundancy and has heartbeat monitoring of appliance.

Features :: Aggregation, Filtering, Load Balancing, Any-to-Any and Multicast Connections, Multistage Filtering, and Port Tagging.

Part Number :: ACI-3030-T05-M1 (Bypass Switch Blade, Multimode Ports) ACI-3030-T05-S1 (Bypass Switch Blade, Single-mode Ports)

Interfaces :: 5 pair × 1/10G optical bypass taps | Bypass mode: passive optical tap | Through mode: in-line appliance

User :: 14 × 1/10G Ethernet (SFP/SFP+) Enable up to 7 in-line appliances Enable up to 14 monitor ports

Heartbeat :: Monitors appliance health | Bypass when Heartbeat fails | Select interval 500ms to 5sec | Select missed Heartbeat packet threshold

SFP/SFP+ :: 1000BASE-T/SX/LX, 10GBASE-SR/LR

Blade Performance :: All ports line rate > 200 byte packets

XR Backplane :: 360 Gbps backplane connectivity per blade

WebXR

WebXR and WebX web-based graphical interfaces enable engineers to build, save, view and recall device connections between SPANs/TAPs and monitoring tools using intuitive, Visio-like diagrams.

Drag and drop diagramming screen
Global View screen for managing connections and organizing diagrams
Source port sharing
Port tagging labels ingress traffic
Import/export filters
Embedded software – no installation required
Web accessible

TitanXR

TitanXR provides a single, centralized point of switch management for network monitoring in a multi-switch environment.

Mobile App — a convenient centralized interface for globally managing APCON switches from a single location. Now you can see it in real-time — all from a smartphone.

Easily create connections to multiple APCON switches
Web accessible interface
Single login and screen access to all switches
Customize graphs and dashboards
Manage system-to-system trunking
User authentication and management
Schedule software updates and configuration backups
Generate and export a variety of reports.

IntellaStore II+ Blade

IntellaStore II+ Blade includes dedicated data capture and storage for on-board traffic analysis and advanced multi-function features. With 12 ports 1G/10G and 2 ports 40G Ethernet, this blade is ideal for advanced network monitoring applications at mid-size businesses or remote locations.

Part Number :: ACI-3033-S14-2

SFP/SFP+ :: 1000BASE-T/SX/LX, 10GBASE-SR/LR

QSFP :: 40GBASE-SR4/LR4

Blade Performance :: All ports line rate > 200 byte packets

XR Backplane :: 360 Gbps backplane connectivity per blade

Application Processor :: Intel® Xeon® E3-1515M v5

XR Base Features :: Aggregation, Filtering, Load Balancing, Any-to-Any and Multicast Connections, Multi Stage Filtering and Port Tagging.

Comparison Table :: IntellaStore II / IntellaStore II+

Traffic Buffering :: IntellaFlex Traffic Manager Blade

Data monitoring switch with 36 ports 1G/10G Ethernet. Enhanced buffering and burst absorption with deep 15GB ingress buffers. Buffer and rate shape up to 360Gbps of traffic to alleviate tool oversubscription.

Features :: Traffic aggregation, flow control and port tagging – Load balancing within each group of 12 ports.

Part Number :: ACI-3032-B36-1

Interface Type :: 1 Gbps/10 Gbps Ethernet

Physical Interfaces :: 36 SFP+ ports

SFP+ Ports :: 1000BASE-LX or 1000BASE-SX 1G Ethernet, 10GBASE-LR or 10GBASE-SR 10G Ethernet

XR Backplane :: 360Gbps backplane connectivity per blade

Aggregation / Filtering :: NEW | IntellaFlex 40G Packet Aggregator Blade

IntellaFlex 40G High-Density Packet Aggregator Blade includes 20 ports 40G Ethernet with network monitoring aggregation, filtering and load balancing features. This blade is optimized for Ethernet network monitoring applications.

Features :: Aggregation, Filtering, Load Balancing, Any-to-Any and Multicast Connections, Multi Stage Filtering, and Port Tagging.

Part Number :: ACI-3030-E20-1

Interfaces :: 20 × 40G QSFP Ethernet

QSFP :: 0GBASE-SR4/LR4

XR Backplane :: 360Gbps backplane connectivity per blade
